Crate oxidant

Main entry point for Kataglyphis.

OxidANT

The Kataglyphis family's Rust crates (core, telemetry, inference, media, gui, cli, webgpu_renderer, observant) and the Rust best practices they follow. Part of the Kataglyphis Ecosystem for robust code sharing and rapid development.

For official docs follow this link.

A push to develop and every PR run Linux x64 (its feature check included) and the gates; Linux arm64, Linux riscv64, Windows x64 and Windows arm64 (cross-built, then run on a real arm64 runner) run on request, through a ci token in a commit message or by hand, and all five before a release from main (the family’s strategy). A lane’s badge above shows its runs started by hand; a requested run is listed under On request. See AGENTS.md.

Table of Contents

• About The Project
  • The crates
  • Dependencies
  • Useful tools
• Getting Started
• Tests
• Run
  • The cat cam
• Analysis
• Docs
• Updates
  • Dependency upgrades: Renovate as a local CLI
  • Installed cargo binaries
• Cameras
• Contributing
• License
• Contact
• Literature

About The Project

OxidANT is the Kataglyphis family’s Rust workspace: the crates two other repositories build as a submodule, plus the Rust practices, gates and packaging they all inherit. It started as a project template and that scaffolding is still here — CI lanes, MSIX/MSI packaging, Renovate, lint gates, a feature matrix — but the crates are real code with real consumers rather than placeholders.

The largest of them is crates/webgpu_renderer, a WebGPU (wgpu) glTF renderer that runs natively (Vulkan/DX12/Metal) and in the browser (wasm32 + WebGPU): PBR with IBL, cascaded shadow maps, SSAO, bloom, GPU skinning, animations, LOD, hot shader reload, and headless golden tests. See crates/webgpu_renderer/README.md for the demos, and for how it shares its shaders with the C++ Vulkan engine in BeschleunigerBallett: one Slang source compiles to the engine’s SPIR-V and to the WGSL checked in under crates/webgpu_renderer/src/shaders/ (histogram.wgsl alone is hand-written).

Containers, PowerShell and CI plumbing are not duplicated here. They belong to Kataglyphis ANTfrastructure, the submodule under third_party/ that every repository in the family shares — see AGENTS.md before writing a helper.

The crates

One Cargo workspace. The root Cargo.toml is both the workspace and the root package oxidant — a cdylib/staticlib/rlib library whose consumers are other repositories, so its [lib] name is not free to change.

Crate	Package	What it is
crates/core	kataglyphis_core	Config, detection types, logging
crates/telemetry	kataglyphis_telemetry	CPU/GPU/RAM resource monitoring
crates/inference	kataglyphis_inference	ONNX backends, feature-gated: onnx_tract, onnxruntime, onnxruntime_directml, onnxruntime_cuda
crates/media	kataglyphis_media	GStreamer capture, feature-gated (gstreamer)
crates/gui	kataglyphis_gui	Feature-gated GUI: gui_windows, gui_linux, gui_wgpu, gui_unix
crates/webgpu_renderer	kataglyphis_webgpu_renderer	wgpu glTF renderer, native and wasm32/WebGPU: PBR+IBL, cascaded shadows, SSAO, bloom, skinning, animations, LOD, headless golden tests
crates/observant	kataglyphis_observant	ObservANT service (cats by default): picks the camera, YOLO cat boxes, WebRTC, and the web server for OmniAccelerANT’s Stream page
crates/cli	kataglyphis_cli	The CLI binary (read / stats / gui, plus onnx-runtime with an onnxruntime_* feature and media-check with gui_windows)
src/	oxidant	The root package: the flutter_rust_bridge surface for OmniAccelerANT, plus the feature-gated burn-demos bin

Default features are empty. GUI, ONNX, GStreamer and the burn demos only compile with an explicit --features (see Run), and each one needs system libraries — AGENTS.md has the feature/dependency table.

Two repositories build this one as a submodule, so a rename has to be carried into both: OmniAccelerANT (the root package through flutter_rust_bridge, and crates/observant) and BeschleunigerBallett (the root package as a staticlib through Corrosion, and crates/webgpu_renderer through cargo for its wasm demo and its tests).

Dependencies

Crate versions live in Cargo.toml/Cargo.lock; the third_party/ANTfrastructure gitlink is a dependency too, and the one that silently changes every gate.

For the newest versions your current constraints already allow (Cargo.lock only, no manifest edit):

cargo update

To move the manifests as well:

cargo install cargo-edit
cargo upgrade --dry-run --verbose
cargo upgrade --incompatible

To see what is behind before moving anything — crates and the gitlink, which is decided by Renovate rather than by a version bound — see Dependency upgrades.

One lockfile entry is pinned by hand: zune-core is held at 0.5.1 because 0.5.2 broke zune-jpeg 0.5.15 in release builds. 0.5.2 has since been yanked, and 0.5.3 compiles with zune-jpeg 0.5.15 (checked 2026-09-25), so a bare cargo update now resolves a working version. AGENTS.md has the detail.

Useful tools

• cargo-outdated

Getting Started

You need a Rust toolchain, a C++ compiler and the submodule. The toolchain version the CI images and every gate use is RUST_VERSION in third_party/ANTfrastructure/linux/scripts/01-core/versions.env — read it there rather than pinning a number here, which is how the last one went stale. The C++ compiler is for the root package’s build.rs, which compiles the cxx bridge in src/native_only.rs (on Windows, the Visual Studio C++ build tools, which the MSVC Rust toolchain needs to link anyway). Nothing else is needed for a default-feature build.

Search the tree with ripgrep (rg): winget install --id BurntSushi.ripgrep.MSVC -e --scope user on Windows, apt install ripgrep on Linux.

git clone --recurse-submodules https://github.com/Kataglyphis/OxidANT.git
cd OxidANT
cargo build --workspace --locked

An existing clone without the submodule: git submodule update --init --recursive.

Tests

Run the complete suite (unit + integration + proptest fuzz + doc tests) at the debug profile, as every CI lane does:

KATAGLYPHIS_REQUIRE_GPU=1 cargo test --workspace --locked \
    --features 'kataglyphis_media?/gstreamer,kataglyphis_inference?/onnxruntime'

The two features reach the suites a default build compiles empty: kataglyphis_media’s capture tests are cfg(feature = "gstreamer") and need GStreamer installed, and the inference crate’s ORT-loader tests are cfg(feature = "onnxruntime"). The ?/ form names each member’s own feature. Plain kataglyphis_media/gstreamer would also switch on the optional kataglyphis_media dependency of kataglyphis_gui and the root package, because with --workspace cargo applies dep/feature to every selected package.

CI additionally gates on formatting and lints, both as hard failures. Run them before pushing:

cargo fmt --all -- --check
cargo clippy --workspace --all-targets --locked \
    --features 'kataglyphis_media?/gstreamer,kataglyphis_inference?/onnxruntime' -- -D warnings

The crates/webgpu_renderer headless golden tests need a GPU adapter and silently skip without one. KATAGLYPHIS_REQUIRE_GPU=1 turns a missing adapter into a failure, so a green run actually means they rendered. Every CI lane that renders sets it: the Linux lanes render on the image’s software Vulkan device (lavapipe), the Windows lanes on the runners’ software Direct3D 12 adapter (WARP). Each GPU test binary prints one ADAPTER: line to stderr when it first gets a device (GpuContext::headless_or_skip()), naming the adapter and whether it offers BC textures and timestamp queries; every CI adapter offers both, so under KATAGLYPHIS_REQUIRE_GPU the BC-upload and GPU-timing tests fail instead of skipping without them.

The suites live in:

• Unit tests inside the workspace crates (kataglyphis_telemetry, kataglyphis_inference, and the renderer’s own suite).
• Integration tests: tests/integration/integration.rs, which run the CLI and are compiled as kataglyphis_cli’s integration test (crates/cli/tests/integration.rs); crates/media/tests/capture_test.rs (a videotestsrc pipeline and camera enumeration); and the renderer’s 18 binaries under crates/webgpu_renderer/tests/.
• Property-based (fuzz) tests: proptest properties on ObservANT’s network-facing parsers (Range header, query, Host/Origin check, request path, camera spec, config file), 256 random inputs per property and run, in each module’s properties tests. There is no separate cargo-fuzz/libFuzzer setup.

On Windows the renderer’s tests run outside the container. Any of its test binaries links wgpu, and wgpu’s gles backend makes the executable import opengl32.dll at load time; Windows Server Core does not ship that DLL, so the process dies with 0xc0000135 (STATUS_DLL_NOT_FOUND) before main. The loader resolves that import, so no runtime flag avoids it — and letting it run turned the entire cargo test --workspace into a crash with no results. The gles feature is kept deliberately: it is the OpenGL fallback for machines without Vulkan/DX12. Run those tests on a desktop Windows host, where the DLL exists:

$env:KATAGLYPHIS_REQUIRE_GPU = '1'; cargo test -p kataglyphis_webgpu_renderer --locked

That is the CI split too. In windows-x64.yml the container half (Invoke-WindowsLane.ps1, which starts with Invoke-DebugTests.ps1) runs the workspace tests except the renderer’s, then builds the renderer’s lib and integration tests and lists the executables in target\host-tests\tests.json. The lane’s host-command runs them on the runner, a desktop Windows Server with opengl32.dll, through Invoke-HostTests.ps1 and the hub’s Invoke-StagedTests.ps1. It fails if the list, a binary or a passing test is missing, so it can never report green over nothing. windows-arm64-cross.yml builds the whole workspace’s tests for arm64 (Stage-CrossTests.ps1) and runs them all on windows-11-arm with the same runner script.

Run

The CLI is its own package, not the root one (whose only bin is burn-demos), so cargo run needs -p kataglyphis_cli:

cargo run -p kataglyphis_cli -- read --path README.md

The cat cam

crates/observant is one service: the camera, YOLO cat boxes, a WebRTC stream and the web page that plays it. It needs GStreamer and the chain-built ONNX Runtime, so try it in the family :latest image:

cargo build --release -p kataglyphis_observant
target/release/kataglyphis_observant --camera test --print-config  # the settings in effect
target/release/kataglyphis_observant --camera test                 # a test pattern, no camera
curl localhost:8080/healthz                    # ok or the problem, the camera, the model's runs, the cat, the kept clips
curl -o frame.jpg localhost:8080/snapshot.jpg  # the current picture, boxes included
curl -o cat.jpg localhost:8080/arrival.jpg     # the frame the last cat arrival was seen on
curl -o cat.jpg 'localhost:8080/arrival.jpg?t=1791763273'  # one of the last five, by arrival time
curl -o cat.mp4 localhost:8080/arrival.mp4     # that arrival as H.264, 3 s before it to 7 s after
curl -o cat.mp4 'localhost:8080/arrival.mp4?t=1791763273'  # one of the last five, by arrival time
curl localhost:8080/settings                   # what the settings page can change
curl -X POST -H 'content-type: application/json' -d '{"rotate": 270, "score": 0.5}' localhost:8080/settings
curl -X POST -H 'content-type: application/json' -d '{"ignore": [[0.25, 0.75, 0.75, 1.0]]}' localhost:8080/settings  # "not a cat" here

A cat arrives only where something moved in the last 10 s, and a detection over a spot in ignore (fractions of the picture) never counts. /webrtc-ws and POST /settings take only the cat cam’s own page (a browser’s Origin must match a local Host; a reverse proxy’s name goes into allowed_hosts), at most max_viewers tabs watch at once (8), and the origins in peers may read this one’s status and pictures for their overview.

--notify-url <http(s) URL> (notify_url in the file) POSTs a JSON event there whenever a cat arrives or leaves, a Home Assistant webhook trigger for instance, and a clip event once the arrival’s video is encoded. A departure names the arrival it ends (arrived, best_score), so a receiver can update what it sent for that arrival. --precompress <web build> writes a zopfli .gz beside each file the server gzips and exits; a packager runs it once, and the server then sends those files as they are. clip_seconds (default 10, 0 for none) sets that video’s length; it needs openh264enc, h264parse and mp4mux, and without them the service records none and says so at start.

The settings come from a TOML file (--config, else /etc/omni-accelerant/catcam.toml) with the flags on top; --web-root names OmniAccelerANT’s web build, served on :8080. OmniAccelerANT packages the service as a .deb, AppImage, flatpak, MSI and MSIX. How it picks the camera and paces the model, and the measurements behind both: AGENTS.md § The cat cam service.

Windows: GStreamer + ONNX Overlay (WGPU)

Build + Run (CPU via tract):

cargo run -p kataglyphis_cli --features gui_windows,onnx_tract -- gui --backend dx12

Every onnxruntime* feature loads ONNX Runtime at run time and downloads nothing at build time. The only ORT it may load is the family’s chain build (owner rule 2026-09-23): inside the Windows image that is $env:ONNX_ROOT\bin\onnxruntime.dll, found automatically; anywhere else, stage that file (plus DirectML.dll and onnxruntime_providers_shared.dll) next to the exe or point ORT_DYLIB_PATH at it. There is no fallback to the onnxruntime.dll Windows ships in System32, and any file that is not the chain build (a pip wheel’s, a GitHub release’s) is refused at load time. The portable bundle (dist\windows-<x64|arm64>\bundle), MSIX and MSI carry the chain copy already.

To check which ONNX Runtime an exe gets without starting the GUI, build it with an onnxruntime_* feature and run its onnx-runtime subcommand; it prints the path it loaded, or fails when no chain ORT loads. Both Windows lanes run it on the packaged exe:

cargo run -p kataglyphis_cli --features onnxruntime_directml -- onnx-runtime

The GUI creates its camera pipeline’s GStreamer elements by name (mfvideosrc, falling back to autovideosrc, then videoconvert, capsfilter, appsink), so their plugins are in no import table. Every Windows package therefore carries them in lib\gstreamer-1.0, and the DLLs they import beside the exe; the list is Build.GStreamerPlugins in scripts/windows/Build-Windows.config.psd1. The media-check subcommand (with gui_windows) builds that pipeline without starting it, so with no camera and no window, and prints the plugin file behind each element; an exe that carries plugins must take every element from them. Both Windows lanes run it on the packaged exe:

cargo run -p kataglyphis_cli --features gui_windows -- media-check

Build + Run (ONNX Runtime + DirectML):

cargo run -p kataglyphis_cli --features gui_windows,onnxruntime_directml -- gui --backend dx12

Build + Run (ONNX Runtime + CUDA, NVIDIA):

# PowerShell
$env:KATAGLYPHIS_ORT_DEVICE="cuda"
cargo run -p kataglyphis_cli --features gui_windows,onnxruntime_cuda -- gui --backend dx12

# CMD
set KATAGLYPHIS_ORT_DEVICE=cuda
cargo run -p kataglyphis_cli --features gui_windows,onnxruntime_cuda -- gui --backend dx12

Optional environment variables:

• KATAGLYPHIS_ONNX_MODEL – path to the ONNX model. Unset, the app takes resources\models\deim_dfine_n_coco.onnx beside its exe, where the portable bundle, the MSIX and the MSI all put it, and otherwise the checkout’s resources/models/deim_dfine_n_coco.onnx, a path fixed at compile time. Models are not tracked: scripts/linux/fetch-models.sh (Windows: scripts/windows/Get-Models.ps1) downloads what resources/models/models.lock names and checks its SHA-256
• KATAGLYPHIS_ONNX_BACKEND – tract or ort (default: automatic)
• KATAGLYPHIS_ORT_DEVICE – cpu | auto | cuda (default: cpu)
• KATAGLYPHIS_ORT_THREADS – ONNX Runtime’s intra-op threads (default: 0, one per core)
• KATAGLYPHIS_ORT_SPIN – 0 stops idle ONNX Runtime threads spin-waiting for the next run (default: ORT’s, spinning). Worth it when inference runs at a capped rate: the cat cam sets it itself
• KATAGLYPHIS_PREPROCESS – letterbox | stretch (default: stretch)
• KATAGLYPHIS_SWAP_XY – set to 1 if the model output swaps X and Y (default: 0)
• KATAGLYPHIS_SCORE_THRESHOLD – detection score threshold (default: 0.5)
• KATAGLYPHIS_INFER_EVERY_MS – minimum interval between inference requests in ms (default: 0: the next frame goes out as soon as the previous result is back)

CUDA notes:

• Needs the NVIDIA driver plus the CUDA/cuDNN runtime on the machine, and a chain-built ONNX Runtime with the CUDA provider beside onnxruntime.dll. Nothing is copied from a download cache any more.
• If registering the CUDA provider fails, KATAGLYPHIS_ORT_DEVICE=auto falls back to ONNX Runtime on the CPU. An ONNX Runtime built without the CUDA provider is not covered by that: auto then gives up on ORT and uses tract if the build has onnx_tract, and fails otherwise.

The overlay shows FPS, inference latency, CPU/RSS and a CPU history, and inference can be toggled from it.

Analysis

cargo +nightly check --manifest-path Cargo.toml --target wasm32-unknown-unknown -Z build-std=std,panic_abort

Resource usage logging (CPU/GPU/RAM)

cargo run -p kataglyphis_cli --features gui_windows,onnxruntime_directml -- --resource-log --resource-log-interval-ms 1000 --resource-log-gpu=true gui

Optional, also write it to a file:

cargo run -p kataglyphis_cli --features gui_windows,onnxruntime_directml -- --resource-log --resource-log-file .\resource.log gui

Burn / PyTorch-replacement demos

A separate binary, behind the burn_demos feature.

cargo run --features burn_demos --bin burn-demos -- --help

Examples:

cargo run --features burn_demos --bin burn-demos -- tensor-demo

cargo run --features burn_demos --bin burn-demos -- linear-regression --epochs 50 --steps-per-epoch 50 --lr 0.02 --batch-size 256

cargo run --features burn_demos --bin burn-demos -- xor --epochs 2000 --lr 0.05

cargo run --features burn_demos --bin burn-demos -- two-moons --epochs 200 --steps-per-epoch 50 --lr 0.01 --batch-size 256

# ONNX Runtime detector demo (default model: resources/models/deim_dfine_n_coco.onnx; fetch it first)
scripts/linux/fetch-models.sh
cargo run --features burn_demos --bin burn-demos -- onnx-detector --runs 1 --print-topk 3

Windows

cargo run -p kataglyphis_cli --features gui_windows -- gui --backend dx12

# Vulkan backend
cargo run -p kataglyphis_cli --features gui_windows -- gui --backend vulkan

# Auto-select (wgpu PRIMARY; also the default)
cargo run -p kataglyphis_cli --features gui_windows -- gui --backend auto

Windows: build & test in the Stevedore container

The workspace builds and tests inside the Kataglyphis ANTfrastructure Windows developer image using Stevedore’s docker.exe. The image reference is not written down anywhere in this repository — including here — because ANTfrastructure’s linux/scripts/01-core/versions.env owns it; the driver asks Get-CiImageReference -Windows for it and -Image overrides for a one-off. To see the current value: pwsh -c "Import-Module third_party/ANTfrastructure/windows/scripts/modules/WindowsContainerImage.Common.psm1; Get-CiImageReference -Windows".

ANTfrastructure is the ground truth for container and PowerShell functionality. The scripts here are thin drivers: docker.exe discovery, isolation flags, container teardown, SDK-tool lookup, MSIX manifest expansion, config access and build-step logging all come from its modules under windows/scripts/modules/. Before adding a helper to scripts/windows/, check whether ANTfrastructure already has it — several that were written locally turned out to exist there in a better form. Everything is pwsh (PowerShell 7+); nothing here runs under Windows PowerShell 5.1.

The driver bind-mounts this repository directly into the container (as C:\ws-mnt) — no copy, so artifacts land straight in your tree and third_party/ is available inside. It builds all three profiles (dev/debug, profile = release + debuginfo, release = fat LTO) and optionally the full debug test suite:

# build debug + profile + release in the container
pwsh -ExecutionPolicy Bypass -File .\scripts\windows\container\Invoke-StevedoreBuild.ps1

# build AND run cargo test --workspace (unit + integration + proptest fuzz + doc)
pwsh -ExecutionPolicy Bypass -File .\scripts\windows\container\Invoke-StevedoreBuild.ps1 -Test

# only if your host refuses the mount (see below)
pwsh -ExecutionPolicy Bypass -File .\scripts\windows\container\Invoke-StevedoreBuild.ps1 -StageSources

Dev Drive (ReFS) is not a blocker — reading through a bind mount works. What does not work is create-then-rename through it (bindFlt rejects copySync/renameSync with errno 3), which is precisely what cargo does. The driver keeps every build write container-local (CARGO_TARGET_DIR=C:\ct, CARGO_HOME=C:\ch), so only a plain artifact copy crosses the mount. If a host really does refuse it, docker run fails at once with “Der Dateisystem-Minifilter kann nicht an das Entwicklervolume angefügt werden”; fix it permanently with one elevated fsutil devdrv setFiltersAllowed /volume D: "bindFlt,wcifs" and a remount, or use -StageSources meanwhile. Note the two parts people get wrong: /volume is required, and the filter list is ONE quoted argument – see third_party/ANTfrastructure/docs/windows-container-build-performance.md for the owning explanation. fsutil devdrv query needs elevation itself, so a failing query tells you nothing — just try the mount.

Artifacts land in target\container\{debug,profile,release} and are mirrored to the (gitignored) repo-root debug\, profile\, release\ folders; each contains the CLI exe, cdylib (.dll + import lib), staticlib (.lib) and pdb. Latest verified run (2026-08-07, rustc 1.97.1): all three profiles built (debug 1m35s, profile 1m32s, release 1m12s), written straight into the repo through the mount, and the binaries run on the host, e.g.:

.\release\kataglyphis_cli.exe stats --path .\README.md

Host caveats the driver handles automatically. ANTfrastructure is the authority on all of this — these are pointers, not a second copy:

• --isolation process for the full host CPU count (Hyper-V isolation caps at 2), via Get-ContainerIsolationArgs.
• All cargo writes stay container-local (CARGO_TARGET_DIR=C:\ct, CARGO_HOME=C:\ch); only a plain artifact copy crosses the mount, because bindFlt rejects create-then-rename.
• A dropped docker CLI pipe does not mean the build died — the driver waits on the actual container state with upstream’s Wait-ContainerExit (bounded at 60 min per phase), and tears containers down with Remove-BuildContainerSafe. A failed run’s container is kept so docker logs still works.

Topic	Read
Setting up a Windows host for Stevedore (services, docker-users, CNI nat conf)	docs/windows-host-setup.md
Windows container internals: wcifs/bindFlt, process isolation, layer-commit bug	docs/windows-builds.md
Running Linux containers on Windows (Rancher Desktop)	docs/rancher-desktop-linux-containers.md
Wiring a new project to all of it	docs/adopting-in-a-new-project.md

Linux containers locally (Rancher Desktop)

The Linux image is always the family CI one, in CI and locally — the same reference the workflows inherit, printed by bash third_party/ANTfrastructure/linux/scripts/ci-image-ref.sh and owned by that submodule’s versions.env. The command below asks for it rather than repeating it, so it cannot go stale on a tag bump. Rancher Desktop defaults to the containerd engine, so use nerdctl, not docker — and from Git Bash disable path mangling or the mount argument is destroyed. Full instructions: docs/rancher-desktop-linux-containers.md.

$env:MSYS_NO_PATHCONV=1; $env:MSYS2_ARG_CONV_EXCL='*'
$image = bash third_party/ANTfrastructure/linux/scripts/ci-image-ref.sh
rdctl shell nerdctl --namespace default run --rm --user root `
  -v kata-cargo-cache:/cargo-cache `
  -v /mnt/d/path/to/repo:/workspace -w /workspace `
  $image `
  bash -lc 'export CARGO_HOME=/cargo-cache; bash third_party/ANTfrastructure/linux/scripts/02-toolchain/rust/cargo_release.sh'

Two things that will bite on a Windows checkout, both verified 2026-08-07:

• Shell scripts must be LF. .gitattributes enforces it, but a checkout older than that rule keeps CRLF and bash dies on set: pipefail\r: invalid option name. One-time fix: git ls-files -z '*.sh' | xargs -0 rm -f && git checkout -- .
• CARGO_HOME in the image is root-owned, so point it at a writable path (a named volume keeps the registry across runs).

Windows MSIX packaging

Needs the Windows SDK (makeappx, signtool) — located by ANTfrastructure’s Resolve-WindowsSdkToolPath, which honours VsDevCmd’s WindowsSdkVerBinPath / WindowsSDKVersion — and PowerShell 7+ (pwsh): every script here carries #requires -Version 7.0 and will not start under 5.1. The pack itself is ANTfrastructure’s Invoke-MsixPackage; this repo supplies only the staging directory (the release exe, the DLLs beside it, resources/) and the token map.

The normal route is Build-Windows.ps1. It packages MSIX itself, as its MSIX Packaging step, taking every value from the Msix block of scripts/windows/Build-Windows.config.psd1 and letting an environment variable override each one (MSIX_PACKAGE_NAME, MSIX_DISPLAY_NAME, …). -SkipMsix turns it off. The package lands in dist\windows-<x64|arm64>\msix\, beside the portable bundle and the MSI, and carries the exe’s whole DLL closure.

pwsh -ExecutionPolicy Bypass -File .\scripts\windows\Build-Windows.ps1

The same route signs. Its MSIX step signs with the first *.pfx at the repository root (*.pfx is gitignored) and MSIX_PFX_PASSWORD, then verifies the signature. With no .pfx there it warns and the package stays unsigned, which is what CI builds. ANTfrastructure’s GenerateCertificateMSIX.ps1 makes a test certificate. Its -Publisher must be the manifest’s publisher, CN=Kataglyphis (the Msix block’s Publisher):

pwsh -File .\third_party\ANTfrastructure\windows\scripts\certificates\GenerateCertificateMSIX.ps1 `
  -Password '<TEST_CERT_PASSWORD>' -Publisher 'CN=Kataglyphis' -PfxPath .\Kataglyphis.OxidANT.testcert.pfx
$env:MSIX_PFX_PASSWORD = '<TEST_CERT_PASSWORD>'
pwsh -ExecutionPolicy Bypass -File .\scripts\windows\Build-Windows.ps1

An existing PFX works the same way, and its subject must match the publisher too. The package is dist\windows-<arch>\msix\Kataglyphis.OxidANT_<VERSION>_<arch>.msix, with Cargo.toml’s [workspace.package] version padded to four parts (2.3.4 becomes 2.3.4.0). ANTfrastructure’s standalone New-MsixPackage.ps1, which this section used to show, cannot package this repo: it fills __PACKAGE_NAME__-style tokens, while packaging/msix/AppxManifest.template.xml carries the __MSIX_*__ tokens that Build-Windows.ps1 fills.

Installing a test-signed package needs its certificate trusted machine-wide first, in LocalMachine\Root and LocalMachine\TrustedPeople, from an elevated PowerShell. The steps and the errors they prevent (0x800B0109, Access denied, Get-AppxLog) are in ANTfrastructure’s certificates README. With this repo’s names (repo-relative, so they hold in any checkout):

Add-AppxPackage -Path 'dist\windows-x64\msix\Kataglyphis.OxidANT_2.3.4.0_x64.msix'

Check, launch, update, remove:

Get-AppxPackage -Name Kataglyphis.OxidANT | Select-Object Name, PackageFullName, Status

$pkg = Get-AppxPackage -Name Kataglyphis.OxidANT
Start-Process "shell:AppsFolder\$($pkg.PackageFamilyName)!App"

# update: raise the version in Cargo.toml, rebuild and sign, then install it the same way
Add-AppxPackage -Path dist\windows-x64\msix\Kataglyphis.OxidANT_<NEW_VERSION>_x64.msix

Get-AppxPackage -Name Kataglyphis.OxidANT | Remove-AppxPackage

The package identity changed on 2026-09-05 from Kataglyphis.RustProjectTemplate to Kataglyphis.OxidANT. Windows treats the two as different applications, so an installation predating that date is not upgraded — uninstall it first.

Windows MSI packaging

Runs as the MSI Packaging step of Build-Windows.ps1 (disable with -SkipMsi, or Msi.Enabled = $false in scripts/windows/Build-Windows.config.psd1).

Output: dist\windows-<x64|arm64>\msi\kataglyphis_cli-<VERSION>-<x64|arm64>.msi

It installs the portable bundle’s tree: the exe with every DLL of its closure beside it (the chain ONNX Runtime and the VC++ runtime included), the GStreamer plugins in lib\gstreamer-1.0 and resources\ with the model. wix/main.wxs holds the exe, the licence and the shortcut; the rest is a component group the build generates, one component per file.

Built with WiX Toolset v4 (wix.exe build), not cargo-wix: cargo-wix drives WiX v3’s candle.exe/light.exe even in its newest release (0.3.9), while the container image ships WiX 4.0.6 as a single wix.exe. wix/main.wxs is therefore in the v4 schema and gets version, binary path and licence path as preprocessor variables. The WixUI_FeatureTree dialog set comes from WixToolset.UI.wixext, already installed in the image.

Linux

# WGPU (recommended). The CLI's wgpu GUI feature is gui_windows on every OS;
# it has no gui_wgpu feature.
cargo run -p kataglyphis_cli --features gui_windows -- gui --backend vulkan

# GTK demo
cargo run -p kataglyphis_cli --features gui_unix -- gui

Docs

cargo doc --open

Updates

Dependency upgrades: Renovate as a local CLI

What is behind — the submodule gitlink and the workspace crates — is answered by Renovate run locally, not by a bot. Run it from WSL; it bootstraps a pinned, checksum-verified Node and Renovate on first use.

bash scripts/linux/renovate-local.sh                    # report (default: git-submodules)
bash scripts/linux/renovate-local.sh --managers cargo   # the workspace crates
bash scripts/linux/renovate-local.sh --apply --dry-run  # the plan
bash scripts/linux/renovate-local.sh --apply            # move the gitlink

The Renovate GitHub App is installed on no repo in this family and will not be, so this wrapper is the only thing that ever reads .github/renovate.json. It is not a gate: no workflow runs it and it blocks no commit. --apply moves gitlinks only — the crates stay a cargo upgrade job — and it stages and commits nothing. Details in the script header and in third_party/ANTfrastructure/docs/dependency-updates.md.

Installed cargo binaries

How to update all installed packages:

1. Install updater:

cargo install cargo-update

2. Now update all packages:

cargo install-update -a

Cameras

Raw gst-launch-1.0 pipelines — listing a device’s formats, bisecting a capture problem below the application, Raspberry Pi CSI and V4L2 sources, MJPEG, hardware encoders that under-declare their caps — are ANTfrastructure’s, in third_party/ANTfrastructure/docs/runtime-services.md, § Raw gst-launch-1.0 pipelines (debugging below the app). They were copied here as three bare commands with no explanation of when to reach for them.

Contributing

Contributions are what make the open source community such an amazing place to be learn, inspire, and create. Any contributions you make are greatly appreciated.

1. Fork the Project
2. Create your Feature Branch (git checkout -b feature/AmazingFeature)
3. Commit your Changes (git commit -m 'Add some AmazingFeature')
4. Push to the Branch (git push origin feature/AmazingFeature)
5. Open a Pull Request

License

Distributed under the MIT License. See LICENSE.

Contact

Jonas Heinle - @Cataglyphis_ - jonasheinle@googlemail.com

Project Link: https://github.com/Kataglyphis/OxidANT

Literature

Some very helpful literature, tutorials, etc.

Modules

api

config

logging

platform

resource_monitor

utils

Structs

Detection

A single detection in original image pixel coordinates. Not feature-gated, so api::onnx can name it whichever ONNX backend is enabled.

Functions

rusty_extern_c_integer

C FFI demo stub — returns a fixed integer to verify extern "C" linkage works.
